Запчасти Komatsu PC200EN-6K ЦИЛИНДР РУКОЯТИ(№K-K) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G1

21P-63-K3302

CYLINDER ASS'Y,ARM

|1

21P-63-K3231

CYLINDER ASS'Y

1

21P-63-K3170

ROD,PISTON

2

21P-63-K3181

CYLINDER

3

707-27-13660

HEAD,CYLINDER

4

707-36-13500

PISTON

5

707-41-11840

WASHER

6

01010-81875

BOLT

7

07020-00000

FITTING,GREASE

8

07179-13109

RING,SNAP

9

707-56-95510

SEAL,DUST

10

707-51-95030

PACKING

11

707-51-95630

RING,BUFFER

12

707-52-90710

BUSHING

13

07000-15130

O-RING

14

07001-05130

RING,BACK-UP

15

07000-15130

O-RING

16

07001-05130

RING,BACK-UP

17

707-71-32730

COLLAR

18

707-71-61001

PLUNGER

19

707-44-13920

RING

20

707-39-13510

RING,WEAR

21

707-44-13280

RING,PISTON

22

707-71-60230

PLUNGER

23

04260-00635

BALL,STEEL

24

707-71-91270

CAP

25

07165-16870

NUT

26

707-76-80230

BUSHING

27

07145-00080

SEAL,DUST

28

21P-63-K3190

TUBE

29

07000-13030

O-RING

30

07372-21045

BOLT

31

01643-51032

WASHER

32

07372-21060

BOLT

33

01643-51032

WASHER

34

20D-62-17860

ELBOW

35

07000-13035

O-RING

36

01010-51070

BOLT

37

01643-31032

WASHER

38

707-88-95341

BRACKET

39

707-88-95320

BAND

40

01010-51035

BOLT

41

01643-51032

WASHER

42

07283-22738

CLIP

43

01599-01011

NUT

44

01643-31032

WASHER

45

21P-63-K3210

BRACKET

46

707-88-95320

BAND

47

01010-51035

BOLT

48

01643-51032

WASHER

49

07283-22738

CLIP

50

01599-01011

NUT

51

01643-31032

WASHER
