Запчасти Komatsu PC200EN-6K ЦИЛИНДР СТРЕЛЫ(ПРАВ.) (С КЛАПАН БЕЗОПАСНОСТИ) (ДЛЯ ПРЯМ. СТРЕЛА)(№K-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G1

21P-63-K4302

CYLINDER ASS'Y

|1

21P-63-03440

CYLINDER ASS'Y

1

707-27-12420

HEAD,CYLINDER

2

707-36-12071

PISTON

3

21P-63-52720

ROD ASS'Y,PISTON

4

707-76-80230

BUSHING

5

07145-00080

SEAL,DUST

6

21P-63-52740

SHELL ASS'Y

7

07145-00070

SEAL,DUST

8

707-76-70610

BUSHING

9

01310-01216

SCREW

10

07000-15075

O-RING

11

707-35-90930

RING

12

707-52-90610

BUSHING

13

707-51-85630

RING,BUFFER

14

707-56-85510

SEAL,DUST

15

707-51-85030

PACKING,ROD

16

07000-15110

O-RING

17

707-35-91220

RING,BACK-UP

18

707-44-12911

RING

19

707-44-12180

RING,PISTON

20

707-39-12110

RING,WEAR

21

07179-13099

RING,SNAP

22

07020-00675

FITTING

23

01010-61670

BOLT

24

01643-51645

WASHER

25

21P-62-K3161

TUBE

26

07000-13025

O-RING

27

01010-80860

BOLT

28

01643-50823

WASHER

29

20G-62-K7021

TUBE

30

07372-21035

BOLT

31

01643-51032

WASHER

32

07000-13030

O-RING

33

21P-63-K3220

BRACKET

34

707-88-99210

BAND

35

01010-81030

BOLT

36

01643-51032

WASHER

37

01010-81035

BOLT

38

01643-51032

WASHER

39

702-21-08021

PILOT VALVE ASS'Y,(SEE FIG.Y1665-01A0)

40

07372-21055

BOLT

41

01643-51032

WASHER

42

07372-21060

BOLT

43

01643-51032

WASHER

44

07000-13030

O-RING

45

07002-11423

O-RING

46

07235-10210

ELBOW

47

20E-62-K5181

NIPPLE

48

07002-11423

O-RING

49

07235-10315

ELBOW

50

07002-12034

O-RING
