Запчасти Komatsu PC200EL-6K МОТОР ХОДА (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

21P-60-K1171

MOTOR ASS'Y,TRAVEL

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1641-01A0 TO Y1641-03A0.

|1

21P-60-K1420

ROTARY ASS'Y

|1

ROTARY SUB ASS'Y

1

BLOCK

2

BLOCK

3

PIN,CENTER

4

PISTON

5

RING,SEAL

6

SHIM ASS'Y

7

SPRING

8

PLATE

9

SCREW

10

SHAFT,DRIVE

11

SHIM ASS'Y

12

PLATE KIT,BACK-UP

13

RING,RETAINER

14

BEARING

15

BEARING

16

21P-60-K1430

VALVE ASS'Y,CONTROL

17

21P-60-K1480

HOUSING

18

21P-60-K1490

RING,RETAINER

|19

21P-60-K4490

SEAL KIT,DRIVE SHAFT

19

21P-60-K1510

O-RING (KIT)

20

21P-60-K1520

PLATE,BACK-UP (KIT)

21

21P-60-K1530

O-RING (KIT)

22

21P-60-K1540

SCREW (KIT)

23

21P-60-K1510

O-RING (KIT)

24

21P-60-K5560

SCREW

25

21P-60-K4420

NUT (KIT)

26

20G-60-K1470

SCREW

|$$32

SERVICE KIT

K

21P-60-K4480

SERVICE KIT,TRAVEL MOTOR
