Запчасти Komatsu PC200EL-6K ЦИЛИНДР РУКОЯТИ(ДЛЯ 2-СЕКЦИОНН. СТРЕЛЫ)(№K-K9) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G1

21P-63-K2300

ARM CYLINDER ASS'Y

|$$2

====================

|1

21P-63-K3230

CYLINDER ASS'Y

1

21P-63-K3180

CYLINDER

2

21P-63-K3170

ROD

3

707-27-13660

HEAD

4

707-36-13500

PISTON

5

707-71-61001

PLUNGER

6

07165-16870

NUT

7

707-71-60230

PLUNGER

8

707-71-91270

CAP

9

04260-00635

BALL

10

707-71-32730

COLLAR

11

01010-81875

BOLT

12

707-41-11840

WASHER

13

707-56-95510

SEAL

14

07179-13109

RING

15

707-51-95030

PACKING

16

707-51-95630

RING

17

07000-15130

O-RING

18

07001-05130

RING

19

707-52-90710

BUSHING

20

707-44-13280

RING

21

707-39-13510

RING

22

707-44-13920

RING

23

707-76-80230

BUSHING

24

07145-00080

SEAL

25

07020-00000

FITTING

26

21P-62-K3220

TUBE

27

01010-81060

BOLT

28

01643-51032

WASHER

29

07000-13030

O-RING

30

21P-62-K3210

TUBE

31

07000-13030

O-RING

32

07372-21045

BOLT

33

07372-21060

BOLT

34

01643-51032

WASHER

35

21P-63-K2310

BRACKET

36

707-88-95320

BAND

37

01010-81035

BOLT

38

01643-51032

WASHER

39

07283-22738

CLIP

40

01599-01011

NUT

41

01643-31032

WASHER

42

21P-63-K2320

BRACKET

43

21P-63-K2330

BAND

44

01010-81035

BOLT

45

01643-51032

WASHER

46

07283-22738

CLIP

47

01599-01011

NUT

48

01643-31032

WASHER

|$$52

====================
