Запчасти Komatsu PC200EL-6K МЕХАНИЗМ ПОВОРОТА ПОВОРОТН. КРУГ И КОМПОНЕНТЫ

Схема запчастей Komatsu PC200EL-6K - МЕХАНИЗМ ПОВОРОТА ПОВОРОТН. КРУГ И КОМПОНЕНТЫ
1
2
3
4
5
6
7
8
9
10
11
12
12
12
12
12
13
13
13
14
14
15
16
17
17
18
19
20
21
22
23
24
25
25
26
27
28
29
30
31
32
33
34
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52

Артикул

Название

Примечание

Количество

|1

20G-26-K1111

SWING MACHINERY A.

|1

21P-26-K1112

SWING MACHINERY A.

1

21P-26-K1250

HOUSING ASS'Y

2

SHAFT

3

SPACER

4

21P-26-K1140

SEAL

5

SCREW

6

COVER

7

21P-26-K1170

BEARING

8

HOUSING

9

21P-26-K1230

SEAL

10

21P-26-K1240

BEARING

11

21P-26-K0160

RETAINER

12

21P-26-K1190

WASHER

|12

21P-26-K1190

WASHER

13

21P-26-K1210

PLUG

|13

21P-26-K1210

PLUG

14

21P-26-K0220

TUBE

15

21P-26-K0230

ELBOW

16

21P-26-K1270

GEAR ASS'Y

17

21P-26-K1220

O-RING

18

GEAR ASS'Y

19

GEAR

20

GEAR

21

21P-26-K0090

FLANGE

22

21P-26-K1280

SCREW

23

21P-26-K1290

SCREW

24

21P-26-K1330

GEAR ASS'Y

25

21P-26-K1310

O-RING

26

GEAR

27

GEAR

28

GEAR

29

21P-26-K1340

RING

30

21P-26-K0310

SPACER

31

21P-26-K1350

PLUG

32

21P-26-K1490

HOUSING

33

21P-26-K1360

SCREW

34

21P-26-K1370

O-RING

35

21P-26-K0020

SHAFT

36

21P-26-K0330

DISC

37

21P-26-K0320

DISC

38

21P-26-K0340

SPACER

39

21P-26-K1380

O-RING

40

21P-26-K0040

CARRIER

41

21P-26-K0350

SPRING

42

21P-26-K0030

DISC

43

21P-26-K1390

RING

44

21P-26-K1410

O-RING

45

21P-26-K1420

WASHER

46

21P-26-K1430

ELBOW

47

21P-26-K1440

PLUG

48

21P-26-K1450

SCREW

49

21P-26-K1460

SCREW

50

21P-26-K1510

FLANGE

51

21P-26-K1470

O-RING

52

21P-26-K1480

FILLER

Выбрано товаров: 56
