Запчасти Komatsu PC200CA-6 КОНЕЧНАЯ ПЕРЕДАЧА (СКОРОСТЬ ДВИЖЕНИЯ 1)(№C8-) НИЖНЯЯ ГИДРОЛИНИЯ И ЛИНИЯ ХОДА

1

708-7F-00020

TRAVEL MOTOR ASS'Y

2

150-27-00330

FLOATING SEAL ASS'Y

2

150-27-00264

SEAL RING ASS'Y

2

RING

3

144-873-0310

O-RING ASS'Y

3

O-RING

4

20Y-27-22181

HUB

5

20Y-27-22230

BEARING

6

20Y-27-22280

O-RING

7

20Y-27-22261

LOCK

8

20Y-27-22270

LOCK

9

01010-81020

BOLT

10

20Y-27-22170

CARRIER

11

20Y-27-22140

GEAR

12

20Y-27-22220

BEARING

13

20Y-27-21250

WASHER

14

20Y-27-21230

PIN

15

20Y-27-21290

PIN

16

20Y-27-13310

WASHER

17

20Y-27-22130

GEAR

18

20Y-27-22240

WASHER

19

20Y-27-22150

GEAR

20

20Y-27-22160

CARRIER

21

20Y-27-22120

GEAR

22

20Y-27-22210

BEARING

23

20Y-27-21240

WASHER

24

20Y-27-21220

PIN

25

20Y-27-21280

PIN

26

20Y-27-22110

SHAFT

27

20Y-27-21310

WASHER

28

20Y-27-22250

BUTTON

29

20Y-27-22190

COVER

30

20Y-27-13281

BOLT

31

01643-31645

WASHER

32

07049-01012

PLUG

33

07044-12412

PLUG

34

07002-02434

O-RING

35

20Y-27-11581

SPROCKET

36

20Y-27-11561

BOLT

37

01010-61660

BOLT

38

01643-31645

WASHER

39

20Y-30-21190

COVER

40

01010-81230

BOLT

41

01643-31232

WASHER
