Запчасти Komatsu PC2000-8 ЦИЛИНДР КОВША, ЛЕВ. (№9-) ЦИЛИНДР КОВША

Схема запчастей Komatsu PC2000-8 - ЦИЛИНДР КОВША, ЛЕВ. (№9-) ЦИЛИНДР КОВША
36
37
38
37
38
39
36
9
30
29
27
28
29
30
1
4
3
4
58
40
42
41
34
44
43
8
7
6
7
33
2
32
18
17
19
20
15
14
13
31
5
40
42
41
10
21
12
24
25
26
16
23
22
11
50
49
51
48
57
46
55
56
53
46
35
52
53
46
45
46
47
54
60
59
51
49
50

Артикул

Название

Примечание

Количество

|$0

707-01-0CH11

Cylinder Assembly

|$1

707-01-0K790

Cylinder Assembly

1

707-13-20520

Cylinder

2

707-58-14560

Rod, Piston

3

707-76-12180

Bushing

4

07145-00120

Seal, Dust, (Kit : K08)

5

07043-00108

Plug, Taper

6

707-76-14050

Bushing

7

209-72-11261

Seal, (Kit : K08)

8

07043-00108

Plug, Taper

9

707-71-61540

Plunger

10

707-71-35080

Collar

11

07000-15195

O-ring, (Kit : K08)

12

07001-05195

Ring, Back-up, (Kit : K08)

13

707-71-70350

Plunger

14

04260-00952

Ball

15

707-71-91230

Cap

16

707-27-20920

Head, Cylinder

17

707-56-14740

Seal, Dust, (Kit : K08)

18

07179-14160

Ring, Snap

19

707-51-14870

Packing, Rod

19

707-51-14080

Packing, Rod, (Kit : K08)

20

707-51-14850

Ring, Buffer, (Kit : K08)

21

707-52-91171

Bushing

22

07000-15195

O-ring, (Kit : K08)

23

07001-05195

Ring, Back-up, (Kit : K08)

24

01011-82705

Bolt

25

01643-32780

Washer

26

707-75-14110

Ring, Snap

27

707-36-20561

Piston

27

707-36-20560

Piston

28

707-44-20020

Ring, Piston, (Kit : K08)

29

707-39-20020

Ring, Wear, (Kit : K08)

30

707-44-20910

Ring

31

01310-01232

Screw

31

01310-01232

Screw

32

07000-B5130

O-ring, (Kit : K08)

32

07000-B5130

O-ring, (Kit : K08)

33

07001-05130

Ring, Back-up, (Kit : K08)

33

07001-05130

Ring, Back-up, (Kit : K08)

34

707-86-14270

Tube,L.H.

35

707-87-14670

Elbow,L.H.

36

707-88-26230

Band

37

07372-21240

Bolt

38

01643-51232

Washer

39

707-88-28660

Bracket

40

176-61-41330

Clamp

41

01010-81250

Bolt

42

01643-31232

Washer

43

01010-81280

Bolt

44

01643-31232

Washer

45

01011-81480

Bolt

46

01643-31445

Washer, Flat

47

707-88-28670

Bracket,L.H.

48

707-88-33070

Cap

49

01643-31845

Washer

50

01010-81865

Bolt

51

07371-52080

Flange, Split

52

07000-13048

O-ring, (Kit : K08)

53

01010-81435

Bolt

54

707-88-37421

Plate

55

07371-51470

Flange, Split

56

707-88-33060

Cap

57

01010-81455

Bolt

58

07000-13038

O-ring

59

07378-12010

Head

60

07000-12060

O-ring, (Kit : K09)

Выбрано товаров: 67
