Запчасти Komatsu PC2000-8 КОНЕЧНАЯ ПЕРЕДАЧА, МОТОР ХОДА , ПРАВ. (/) (№9-) КОНЕЧНАЯ ПЕРЕДАЧА

|$0

706-7L-01110

Motor

1

706-8L-41120

O-ring

2

07000-B2012

O-ring

3

04020-01024

Pin, Dowel

4

01252-62055

Bolt

5

01253-62040

Bolt, Hexagon Socket Head

6

706-8L-41510

Shaft, Drive

7

706-8J-41010

Bearing

8

706-8L-41890

Bearing

9

706-8L-41810

Retainer

10

706-8L-05010

Spacer Kit

10

Spacer, T=1.8mm

10

Spacer, T=2.0mm

10

Spacer, T=2.2mm

10

Spacer, T=2.4mm

10

Spacer, T=2.6mm

11

04064-07025

Ring, Snap

12

706-8J-41620

Seal, Oil

13

706-8J-41820

Spacer

14

04065-09030

Ring, Snap, Snap

15

706-8L-41280

Shaft,Center

16

706-8L-41270

Ring,Center

17

706-8L-41290

Spring

18

706-8L-41260

Retainer

19

708-23-12350

Screw

19

706-7L-00120

Block, Cylinder

20

Cylinder Block

21

Plate, Valve

22

706-8L-41610

Piston Subassembly

23

706-8L-91340

Plate

24

706-8L-91370

Disc

25

706-8L-91110

Piston, Brake

26

07000-B5220

O-ring

27

07001-05220

Ring, Back-up

28

07000-B5250

O-ring

29

07001-05250

Ring, Back-up

30

706-8L-91360

Spring
