Запчасти Komatsu PC2000-8 ПОВОРОТНОЕ СОЕДИНЕНИЕ, КОМПОНЕНТЫ (№9-97) ПОВОРОТНОЕ СОЕДИНЕНИЕ

1

21T-64-32421

Block

2

07000-B3048

O-ring

3

01252-71450

Bolt, Hexagon Socket Head

4

02781-00315

Union

5

07002-62034

O-ring

6

02896-61009

O-ring

7

07371-51470

Flange, Split

8

01010-81455

Bolt

9

01643-31445

Washer, Flat

10

21T-62-74121

Block

11

07000-B3048

O-ring

12

07371-51470

Flange, Split

13

01018-31495

Bolt

14

01643-31445

Washer, Flat

15

07371-51470

Flange, Split

16

01010-81455

Bolt

17

01643-31445

Washer, Flat

18

21T-64-36190

Elbow

19

07002-62434

O-ring

20

02896-61009

O-ring

21

02781-00628

Union

22

07002-62434

O-ring

23

02896-61018

O-ring

24

02781-0021D

Union

25

07002-61423

O-ring

26

02896-61008

O-ring

27

19M-61-35140

Tee

28

07002-62034

O-ring

29

02896-61009

O-ring

30

21T-64-36190

Elbow

31

07002-62434

O-ring

32

02896-61009

O-ring

33

207-62-72131

Elbow

34

07002-62434

O-ring

35

11Y-62-11980

O-ring

36

02782-10315

Elbow

37

07002-62034

O-ring

38

02896-61009

O-ring

39

02760-003A5

Hose, Face Seal Type

40

21N-62-12420

Plate

41

209-62-52560

Pin

42

04205-11645

Pin

43

04050-14028

Pin, Cotter

44

01641-21626

Washer

45

21T-62-68350

Bracket

46

01010-82455

Bolt

47

01643-32460

Washer

48

01010-82070

Bolt

49

01643-32060

Washer
