Запчасти Komatsu PC2000-8 ЛЕВ. COVER, ЛЕСТНИЦА РАМА (№9-) ЛЕВ. COVER, POWER ASSIST ЛЕСТНИЦА, ЛЕВ.

1

21T-54-34515

Frame

2

21T-53-32151

Frame

3

21T-53-32170

Bracket

4

01010-81020

Bolt

5

01643-31032

Washer

6

21T-53-32161

Frame

7

21T-53-32170

Bracket

8

01010-81020

Bolt

9

01643-31032

Washer

10

21T-53-31860

Bracket

11

21T-53-31660

Step,Welded

12

01010-81225

Bolt

13

01643-31232

Washer

14

125-43-33861

Spring

15

01011-81270

Bolt

16

01643-31232

Washer

17

01580-01210

Nut

18

01643-31232

Washer

19

21T-54-66130

Pin

20

04065-05220

Ring, Snap

21

101-Z65-2650

Collar

22

06304-06205

Bearing

23

21T-54-15750

Sheave

24

21T-54-66141

Stopper

25

01010-80825

Bolt

26

01643-30823

Washer

27

175-54-34170

Washer

28

01643-31232

Washer

29

01010-81225

Bolt

30

21T-54-15790

Shim, T=1.0mm

31

21T-54-15810

Shim, T=0.4mm

32

21T-54-15820

Shim, T=0.5mm

33

04065-03212

Ring, Snap

34

07016-00206

Seal, Dust

35

01010-81660

Bolt

36

21T-72-12620

Washer

37

01010-81225

Bolt

38

175-54-34170

Washer
