Запчасти Komatsu PC2000-8 ЦИЛИНДР РУКОЯТИ, ПРАВ. (№9-) ЦИЛИНДР РУКОЯТИ

|$0

707-E1-00640

Cylinder Assembly

1

707-13-25230

Cylinder

2

707-58-16250

Rod, Piston

3

707-46-14050

Bushing

4

21T-72-15860

Bushing

5

21T-72-15870

Seal, Dust, (Kit : K07)

6

707-46-14050

Bushing

7

21T-72-15860

Bushing

8

21T-72-15870

Seal, Dust, (Kit : K07)

9

707-71-50390

Plunger

10

04260-01270

Ball

11

707-71-91380

Pin

12

707-27-25310

Head, Cylinder

13

707-56-16740

Seal, Dust, (Kit : K07)

14

707-51-16740

Packing, Rod, (Kit : K07)

15

707-51-16850

Ring, Buffer, (Kit : K07)

16

707-52-91351

Bushing

17

07000-55250

O-ring, (Kit : K07)

18

07001-05250

Ring, Back-up, (Kit : K07)

19

01011-83355

Bolt

20

01011-83360

Bolt

21

01643-33380

Washer

22

707-75-16110

Ring, Snap

23

707-56-16820

Seal, Dust, (Kit : K07)

24

707-88-05080

Ring

25

707-88-39660

Collar

26

707-88-39670

Plate

27

707-36-25221

Piston

28

707-44-25210

Ring, Piston, (Kit : K07)

29

707-39-25011

Ring, Wear, (Kit : K07)

30

707-44-25910

Ring

31

07000-55160

O-ring, (Kit : K07)

32

07001-05160

Ring, Back-up, (Kit : K07)

33

01310-01240

Screw

34

707-86-14360

Tube

35

707-87-14660

Flange

36

707-88-28630

Bracket

37

707-88-28650

Bracket

38

01010-81250

Bolt

39

01643-31232

Washer

40

176-61-41330

Clamp

41

07372-21240

Bolt

42

01643-51232

Washer

43

01010-81450

Bolt

44

01643-31445

Washer, Flat

45

21N-62-18430

Band

46

07000-53048

O-ring, (Kit : K07)

47

07000-52060

O-ring, (Kit : K07)

48

01252-72065

Bolt, Hexagon Socket Head

49

07371-51470

Flange, Split

50

707-88-33060

Cap

51

01010-81455

Bolt

52

07371-52080

Flange, Split

53

707-88-33070

Cap

54

01010-81865

Bolt

55

01643-31845

Washer
