Запчасти Komatsu PC2000-8 ОПОРНЫЙ ЭЛЕМЕНТ ЛЕНИВЦА, ЛЕВ. (№9-) ОПОРНЫЙ ЭЛЕМЕНТ ЛЕНИВЦА

1

21T-30-32540

Yoke,L.H.

2

21T-30-14181

Plunger

3

21T-30-67150

Packing

4

04070-00155

Ring, Snap, for Shaft Side

5

07155-01845

Ring, Wear

6

21T-30-67170

Seal

7

07959-30000

Valve

8

07020-00000

Fitting, Grease

9

209-30-55130

Plate

10

01010-81225

Bolt

11

01643-31232

Washer

12

01011-83070

Bolt

13

01643-33080

Washer

14

21T-30-32511

Guard

15

01010-82045

Bolt

16

01643-32060

Washer

17

21T-30-32522

Plate

18

21T-30-32531

Plate

19

01010-82060

Bolt

20

01643-32060

Washer

|$20

21T-30-00531

Cylinder Assembly

21

21T-30-74220

Plunger

22

21T-30-32351

Cylinder

23

07029-00000

Valve, Relief

24

07179-14160

Ring, Snap

25

07016-11400

Seal, Dust

26

21T-30-74210

Bushing

27

04077-00150

Ring, Snap

28

07155-02045

Ring, Wear

29

21T-30-67160

Packing

30

04070-00175

Ring, Snap, for Shaft Side

31

21T-30-32340

Guide

32

01010-81230

Bolt

33

01643-31232

Washer

34

21T-30-74140

Grand

35

07000-55190

O-ring

36

07001-05190

Ring, Back-up

37

198-30-14420

Plug

38

21T-30-14250

Stopper

39

01010-81225

Bolt

40

01643-31232

Washer

41

01011-82400

Bolt

42

01643-32460

Washer

43

01011-82440

Bolt

44

01643-32460

Washer
