Запчасти Komatsu PC2000-8 ПОВОРОТНОЕ СОЕДИНЕНИЕ, КОМПОНЕНТЫ (№98-) ПОВОРОТНОЕ СОЕДИНЕНИЕ

1

21T-64-32421

Block

2

07000-53048

O-ring

3

01252-71450

Bolt, Hexagon Socket Head

4

02781-00315

Union

5

07002-52034

O-ring

6

02896-51009

O-ring

7

07371-51470

Flange, Split

8

01010-81455

Bolt

9

01643-31445

Washer, Flat

10

21T-62-74121

Block

11

07000-53048

O-ring

12

07371-51470

Flange, Split

13

01018-31495

Bolt

14

01643-31445

Washer, Flat

15

07371-51470

Flange, Split

16

01010-81455

Bolt

17

01643-31445

Washer, Flat

18

21T-64-36190

Elbow

19

07002-52434

O-ring

20

02896-51009

O-ring

21

02781-00628

Union

22

07002-52434

O-ring

23

02896-51018

O-ring

24

02781-0021D

Union

25

07002-51423

O-ring

26

02896-51008

O-ring

27

8296-62-1480

Tee

28

02896-51009

O-ring

29

07002-52034

O-ring

30

02896-51009

O-ring

31

21T-64-36190

Elbow

32

07002-52434

O-ring

33

02896-51009

O-ring

34

207-62-72131

Elbow

35

07002-52434

O-ring

36

208-62-74510

O-ring

37

02782-10315

Elbow

38

07002-52034

O-ring

39

02896-51009

O-ring

40

02762-103A5

Hose, Face Seal Type

41

21N-62-12420

Plate

42

209-62-52560

Pin

43

04205-11645

Pin

44

04050-14028

Pin, Cotter

45

01641-21626

Washer

46

21T-62-68350

Bracket

47

01010-82455

Bolt

48

01643-32460

Washer

49

01010-82070

Bolt

50

01643-32060

Washer
