Запчасти Komatsu PC2000-8 ЦИЛИНДР КОВША (ДЛЯ ЭКСКАВАТ.) (ПРАВ.)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-2

707-01-XP750

CYLINDER GROUP,R.H. (FINAL COATING)

|$3

707-01-0K790

CYLINDER ASS'Y

1

707-13-20520

CYLINDER

2

707-58-14560

ROD,PISTON

3

707-76-12180

BUSHING

4

07145-00120

SEAL,DUST (KIT)

5

707-76-14050

BUSHING

6

209-72-11261

SEAL (KIT)

7

07179-14160

RING,SNAP

8

198-63-93170

SEAL,DUST (KIT)

9

707-27-20920

HEAD,CYLINDER

10

707-51-14080

PACKING,ROD (KIT)

11

07001-05195

RING,BACK-UP (KIT)

12

07000-15195

O-RING (KIT)

13

707-51-14850

RING,BUFFER (KIT)

14

707-52-91171

BUSHING

15

707-75-14110

RING,SNAP

16

01011-82705

BOLT

17

01643-32780

WASHER

18

707-71-35080

COLLAR

19

707-71-61540

PLUNGER

20

07000-B5130

O-RING (KIT)

21

07001-05130

RING,BACK-UP (KIT)

22

707-36-20560

PISTON

23

707-44-20020

RING,PISTON (KIT)

24

707-39-20020

RING,WEAR (KIT)

25

707-44-20910

RING

26

707-71-91230

CAP

27

04260-00952

BALL

28

707-71-70350

PLUNGER

29

01310-01232

SCREW

30

07043-00108

PLUG

31

707-86-14280

TUBE,R.H.

32

07000-13048

O-RING (KIT)

33

01010-81280

BOLT

34

01643-31232

WASHER

35

707-87-14680

BRACKET,R.H.

36

07000-13048

O-RING (KIT)

37

01010-81435

BOLT

38

01643-31445

WASHER

39

01011-81480

BOLT

40

01643-31445

WASHER

41

707-88-28680

BRACKET

42

707-88-37421

PLATE

43

707-88-28660

BRACKET

44

707-88-26230

BAND

45

07372-21240

BOLT

46

01643-51232

WASHER

47

176-61-41330

CLAMP

48

01010-81250

BOLT

49

01643-31232

WASHER

50

707-88-33060

CAP,(FOR SHIPPING)

51

07371-51470

FLANGE,(FOR SHIPPING)

52

01010-81455

BOLT,(FOR SHIPPING)

53

01643-31445

WASHER,(FOR SHIPPING)

54

707-88-33070

CAP,(FOR SHIPPING)

55

07371-52080

FLANGE,(FOR SHIPPING)

56

01010-81865

BOLT,(FOR SHIPPING)

57

01643-31845

WASHER,(FOR SHIPPING)

KIT

707-99-76260

SERVICE KIT
