Запчасти Komatsu PC2000-8 ЦИЛИНДР РУКОЯТИ(ДЛЯ ЭКСКАВАТ.) (ЛЕВ.)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XP720

CYLINDER GROUP,L.H. (FINAL COATING)

|$3

707-01-0K770

CYLINDER ASS'Y

1

707-13-25170

CYLINDER

2

707-58-16170

ROD,PISTON

3

707-46-14050

BUSHING

4

21T-72-15860

BUSHING

5

21T-72-15870

SEAL,DUST (KIT)

6

07179-14180

RING,SNAP

7

566-63-22241

SEAL,DUST (KIT)

8

707-27-25310

HEAD,CYLINDER

9

707-52-91351

BUSHING

10

707-75-16110

RING,SNAP

11

707-51-16030

PACKING,ROD (KIT)

12

707-51-16850

RING,BAFFLE (KIT)

13

07000-15250

O-RING (KIT)

14

07001-05250

RING,BACK-UP (KIT)

15

01011-83330

BOLT

16

01643-33380

WASHER

17

707-36-25220

PISTON

18

707-44-25010

RING,PISTON (KIT)

19

707-39-25011

RING,WEAR (KIT)

20

707-44-25910

RING

21

07000-B5160

O-RING (KIT)

22

07001-05160

RING,BACK-UP (KIT)

23

707-71-91380

PIN

24

04260-01270

BALL

25

01310-01240

SCREW

26

707-71-50390

PLUNGER

27

707-86-14250

TUBE,L.H.

28

07000-13048

O-RING (KIT)

29

01010-81450

BOLT

30

01643-31445

WASHER

31

707-88-28630

BRACKET

32

707-88-28640

BRACKET

33

21N-62-18430

BAND

34

07372-21240

BOLT

35

01643-51232

WASHER

36

176-61-41330

CLAMP

37

01010-81250

BOLT

38

01643-31232

WASHER

39

707-87-14660

BRACKET

40

07000-12060

O-RING (KIT)

41

01252-72065

BOLT

42

707-88-33070

CAP,(FOR SHIPPING)

43

07371-52080

FLANGE,(FOR SHIPPING)

44

01010-81865

BOLT,(FOR SHIPPING)

45

01643-31845

WASHER,(FOR SHIPPING)

46

707-88-33060

CAP,(FOR SHIPPING)

47

07371-51470

FLANGE,(FOR SHIPPING)

48

01010-81455

BOLT,(FOR SHIPPING)

49

01643-31445

WASHER,(FOR SHIPPING)

KIT

707-99-85350

SERVICE KIT
