Запчасти Komatsu PC2000-8 ЦИЛИНДР СТРЕЛЫ(ДЛЯ ЭКСКАВАТ.) (ПРАВ.)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-2

707-01-XP710

CYLINDER GROUP,R.H. (FINAL COATING)

|$3

707-01-0K760

CYLINDER ASS'Y,R.H.

1

707-13-30140

CYLINDER

2

707-58-20270

ROD

3

707-46-18050

BUSHING

4

707-46-18020

BUSHING

5

707-77-18010

SEAL (KIT)

6

01253-63650

BOLT

7

707-41-10270

WASHER

8

07179-15216

RING

9

581-63-92670

SEAL (KIT)

10

707-27-30090

HEAD

11

707-51-20080

PACKING,ROD (KIT)

12

707-51-20850

RING,BUFFER (KIT)

13

707-52-91761

BUSHING

14

707-75-20040

RING,SNAP

15

07000-15300

O-RING (KIT)

16

07001-05300

RING,BACK-UP (KIT)

17

07000-15300

O-RING (KIT)

18

07001-05300

RING,BACK-UP (KIT)

19

707-71-35070

COLLAR

20

707-71-62000

PLUNGER

21

07000-B5185

O-RING (KIT)

22

07001-05185

RING,BACK-UP (KIT)

23

707-36-30110

PISTON

24

707-44-30010

RING,PISTON (KIT)

25

707-39-30900

RING,WEAR (KIT)

26

707-44-30910

RING

27

01310-01640

SCREW

28

707-86-14240

TUBE,R.H.

29

707-86-15020

TUBE,R.H.

30

07000-13048

O-RING (KIT)

31

07000-12060

O-RING (KIT)

32

01010-81450

BOLT

33

01643-31445

WASHER

34

01010-81865

BOLT

35

01643-31845

WASHER

36

707-88-28690

BRACKET

37

707-88-26220

BAND

38

07372-21250

BOLT

39

01643-31232

WASHER

40

707-88-28620

BRACKET

41

01010-81250

BOLT

42

01643-31232

WASHER

43

176-61-41330

CLAMP

44

01010-81840

BOLT

45

01643-31845

WASHER

46

707-88-37410

BRACKET

47

01010-81675

BOLT

48

01643-31645

WASHER

49

707-88-33070

CAP,(FOR SHIPPING)

50

07371-52080

FLANGE,(FOR SHIPPING)

51

01010-81865

BOLT,(FOR SHIPPING)

52

01643-31845

WASHER,(FOR SHIPPING)

53

707-88-33060

CAP,(FOR SHIPPING)

54

07371-51470

FLANGE,(FOR SHIPPING)

55

01010-81455

BOLT,(FOR SHIPPING)

56

01643-31445

WASHER,(FOR SHIPPING)

KIT

707-99-96140

SERVICE KIT
