ГЕНЕРАТОР, AMP

Запчасти Komatsu PC200-8M0 ГЕНЕРАТОР, AMP A

Схема запчастей Komatsu PC200-8M0 - ГЕНЕРАТОР, AMP A
21
20
19
5
3
7
6
1
2
4
30
18
17
14
13
28
22
10
23
27
29
25
17
12
15
16
11
9
24
8
26
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

|$1

600-861-6420

Alternator Assembly, 60Amp.

|$2

ND121400-0800

Frame Assembly

1

ND021100-4210

Stator Assembly

2

ND021401-4980

Frame

3

ND021411-0570

Plate

4

ND021045-0530

Collar

5

ND949006-5590

Screw

6

ND949100-5010

Bearing, Ball

7

ND949043-2000

Bolt

8

ND021501-8050

Frame

9

ND021580-4820

Rectifier Assembly

10

ND021620-2720

Holder Assembly, Brush

11

ND126000-2320

Regulator Assembly

12

ND021551-2480

Cover

13

ND021605-1970

Bushing

14

ND021605-2481

Bushing

15

ND949006-5460

Screw

16

ND913100-4251

Screw

17

ND949056-2481

Nut

18

ND949056-3080

Nut

19

ND021200-8380

Rotor Assembly

20

ND949100-2790

Bearing, Ball

21

ND021506-0070

Cover

22

ND021041-8620

Pulley

23

ND949056-2520

Nut

24

ND021626-0190

Seal

25

ND021626-0250

Seal

26

ND021542-0160

Washer

27

ND949006-6401

Screw

28

ND949007-6280

Screw

29

ND021602-5230

Plate

30

ND92150-06061

Nut
