Запчасти Komatsu PC200-8M0 ГЕНЕРАТОР ( AMP) A

|$1

600-861-3420

Alternator, 35Amp.

|$2

ND121400-4840

Frame Assembly

1

ND021100-5060

Stator Assembly

2

ND021401-1620

Frame

3

ND021411-0570

Plate

4

ND021045-0530

Collar

5

ND949006-5590

Screw

6

ND949100-5010

Bearing, Ball

7

ND949043-2000

Bolt

8

ND121501-2920

Frame

9

ND021580-4670

Rectifier Assembly

10

ND021620-2720

Holder Assembly, Brush

11

ND126000-3730

Regulator Assembly

12

ND021551-2360

Cover

13

ND021605-1970

Bushing

14

ND021605-2950

Bushing

15

ND949006-5460

Screw

16

ND91310-04251

Screw

17

ND949056-2481

Nut

18

ND949056-1001

Nut

19

ND021200-8610

Rotor Assembly

20

ND949100-2790

Bearing, Ball

21

ND021506-0070

Cover

22

ND021041-8620

Pulley

23

ND949056-2520

Nut

24

ND021626-0190

Seal

25

ND021626-0250

Seal

26

ND021542-0160

Washer

27

ND949006-6401

Screw

28

ND949007-6280

Screw

29

ND021602-5230

Plate

30

ND92150-06061

Nut
