Запчасти Komatsu PC200-8M0 ЦИЛИНДР СТРЕЛЫ, R.H ( H) T

|$1

707-E1-01450

CYLINDER ASSY

1

707-13-12740

CYLINDER

2

707-58-85430

PISTON ROD

3

205-70-71360

BUSHING

4

07145-00070

SEAL, DUST, (K08)

5

707-76-80010

BUSHING

6

07145-00080

SEAL, DUST (K08)

7

707-71-34680

COLLAR

8

707-35-31110

RING BACK-UP, (K08)

9

07000-B5110

O-RING, (K08)

10

707-71-70800

PLUNGER

11

707-27-12650

HEAD, CYLINDER

12

707-56-85740

SEAL, DUST (K08)

13

07179-13099

RING, SNAP

14

707-51-85860

PACKING ROD (K08)

15

707-51-85650

RING, BUFFER (K08)

16

707-52-90611

BUSHING

17

707-35-31110

RING, BACK-UP, (K08)

18

07000-B5110

O-RING, (K08)

19

01010-81670

BOLT

20

01643-51645

WASHER

21

707-75-85110

RING, SNAP

22

707-36-12851

PISTON

23

707-44-12150

RING, PISTON (K08)

24

707-39-12140

RING, WEAR (K08)

25

707-44-12911

RING

26

07000-B5075

O-RING, (K08)

27

707-35-30750

RING, BACK-UP (K08)

28

01310-01216

SCREW

29

707-86-69280

TUBE, R.H

30

707-86-16240

TUBE, R.H

31

707-88-51440

BRACKET, R.H

32

07372-21060

BOLT

33

01643-51032

WASHER

34

07372-21045

BOLT

35

01643-51032

WASHER

36

707-88-21620

BAND

37

07000-13030

O-RING (K08)

38

07000-13035

O-RING (K08)

39

07372-21035

BOLT

40

01643-51032

WASHER

41

07283-32738

CLIP

42

07283-33442

CLIP
