Запчасти Komatsu PC200-8M0 КАБИНА(КЛАПАН PPCДЛЯ ХОД) K

|$1

702-22-01010

PILOT VALVE

|$2

702-16-04260

PILOT VALVE

1

BODY VALVE

|$4

BODY, VALVE

2

VALVE

|$6

VALVE

3

702-16-51140

SHIM, T=0.30MM

4

702-16-53420

SPRING

5

702-16-53140

RETAINER

6

702-16-54420

SPRING

7

702-16-53170

PISTON

8

702-16-71150

SEAL

9

702-16-71160

SEAT

10

CASE

11

LEVER

12

SHAFT

13

702-16-73640

PLATE

14

01010-80855

BOLT

15

01643-30823

WASHER

16

01010-80816

BOLT

17

702-16-54331

WASHER, T=1.60MM

|$22

702-16-54341

WASHER, T=1.30MM

|$23

702-16-54351

WASHER, T=1.00MM

|$24

702-16-56380

WASHER, T=1.90MM

|$25

702-16-56390

WASHER, T=2.20MM

18

SPRING PIN

19

BUSHING

20

O-RING

21

702-16-73610

DAMPER ASS'Y

22

01023-10306

SCREW

23

PIN

24

04022-04016

SPRING PIN

25

PLUG

26

PLUG
