Запчасти Komatsu PC200-8M0 ГИДР. БАК. H [ГИДРАВЛИКА]
![Схема запчастей Komatsu PC200-8M0 - ГИДР. БАК. H [ГИДРАВЛИКА]](https://partsell.ru/storage/images/komatsu/KC_EB019/h00074a.png)
45
46
44
47
4
39
34
49
37
38
48
35
36
32
33
30
31
28
27
26
29
24
25
22
23
21
20
19
18
8
6
7
14
12
13
14
12
13
11
9
10
17
15
16
1
49
43
42
2
41
3
2
5
4
50
1
20Y-60-42111
TANK
2
203-60-31100
ELBOW ASSEMBLY
3
203-60-31160
TUBE
4
07044-12412
PLUG
5
07002-12434
O-RING
6
02781-00628
UNION
7
02896-11018
O-RING
8
07002-12434
O-RING
9
02782-10522
ELBOW
10
02896-11015
O-RING
11
07002-12434
O-RING
12
02782-10315
ELBOW
13
02896-11009
O-RING
14
07002-12034
O-RING
15
02782-10311
ELBOW
16
02896-11009
O-RING
17
07002-11423
O-RING
18
207-60-71183
ELEMENT
19
20Y-60-31140
STRAINER
20
20Y-60-31450
VALVE ASSEMBLY
21
20Y-60-21240
SPRING
22
207-60-77131
COVER
23
07000-15195
O-RING
24
01010-81225
BOLT
25
01643-31232
WASHER
-
20Y-60-31171
STRAINER ASSEMBLY
26
207-60-61150
ROD ASSEMBLY
27
20Y-60-21320
HOLDER
28
12R-60-11230
SPRING
29
22B-60-11160
STRAINER
30
20Y-60-42143
COVER
31
07000-15160
O-RING
32
01010-81225
BOLT
33
01643-31232
WASHER
34
208-60-41211
CAP ASSEMBLY
|$36
20Y-60-42220
CAP ASSEMBLY
35
20Y-60-42211
FILLER NECK
|$38
20Y-60-42210
FILLER NECK
36
20Y-60-21340
GASKET
37
01252-70516
BOLT
