Запчасти Komatsu PC200-8M0 РУКОЯТЬ (9MM) (ВНУТР. ЧАСТИ, ЦИЛИНДР КОВША) T [РАБОЧЕЕ ОБОРУДОВАНИЕ]

-

707-E1-X4490

CYLINDER ASSEMBLY

-

724-Z1-13165

CYLINDER, VA

1

707-13-11880

CYLINDER

2

707-58-80871

ROD, PISTON

3

707-76-70110

BUSHING

4

07145-00070

SEAL, DUST\((K04)\)

5

07020-00000

FITTING, GREASE

6

707-76-70120

BUSHING

7

20Y-70-23220

SEAL, DUST\((K04)\)

8

07020-00000

FITTING, GREASE

-

724-Z1-06821

BASIC G.

9

707-27-11870

CYLINDER HEAD

10

707-56-80740

SEAL, DUST\((K04)\)

11

07179-13094

RING, SNAP

12

707-51-80860

PACKING, ROD\((K04)\)

13

707-51-80650

RING, BUFFER\((K04)\)

14

707-52-90561

BUSHING

15

707-35-31060

RING, BACK-UP\((K04)\)

16

07000-B5105

O-RING\((K04)\)

17

01010-81670

BOLT

18

01643-51645

WASHER

19

707-75-80040

RING, SNAP

20

707-36-11880

PISTON

21

707-44-11250

RING, PISTON\((K04)\)

22

707-39-11530

RING, WEAR\((K04)\)

23

707-44-11920

RING

24

01310-01216

SCREW

25

07000-B5070

O-RING\((K04)\)

26

707-35-30700

RING, BACK-UP\((K04)\)

27

707-86-69140

TUBE

28

707-88-47030

BRACKET

|$32

707-88-51140

BRACKET

29

707-88-26660

BAND

30

707-88-47020

CLAMP

|$35

707-88-13590

CLAMP

31

01010-81255

BOLT

|$37

01010-81040

BOLT

32

01643-31232

WASHER

|$39

01643-31032

WASHER

33

07372-21240

BOLT

39

07000-13030

O-RING\((K04)\)
