Запчасти Komatsu PC200-8M0 ЦИЛИНДР РУКОЯТИ T [РАБОЧЕЕ ОБОРУДОВАНИЕ]
![Схема запчастей Komatsu PC200-8M0 - ЦИЛИНДР РУКОЯТИ T [РАБОЧЕЕ ОБОРУДОВАНИЕ]](https://partsell.ru/storage/images/komatsu/KC_EB019/t00348a.png)
1
3
35
2
17
16
19
23
24
26
27
28
29
11
31
32
30
12
7
13
14
41
43
4
28
29
32
5
6
4
33
34
36
40
49
47
50
46
48
42
39
6
20
22
25
18
15
21
9
8
9
10
44
45
37
43
44
45
40
38
41
42
-
707-E1-X1470
CYLINDER ASSEMBLY
-
724-Z1-13131
VARIATION G.
1
721-13-13100
CYLINDER
2
707-58-95270
ROD, PISTON
3
707-76-80010
BUSHING
4
07145-00080
SEAL, DUST\((K03)\)
5
707-76-80010
BUSHING
6
07145-00080
SEAL, DUST\((K03)\)
7
07020-00000
FITTING, GREASE
8
707-71-35140
COLLAR
9
707-35-31260
RING, BACK-UP\((K03)\)
10
07000-B5125
O-RING\((K03)\)
11
707-71-71010
PLUNGER
12
707-71-80320
PLUNGER
13
04260-00635
BALL, STEEL
14
707-71-91270
CAP
-
724-Z1-06886
BASIC G.
15
707-27-13850
HEAD, CYLINDER
16
707-56-95740
SEAL, DUST\((K03)\)
17
07179-13109
RING, SNAP
18
707-52-90721
BUSHING
19
707-51-95860
PACKING, ROD\((K03)\)
20
707-51-95650
RING, BUFFER\((K03)\)
21
707-35-31260
RING, BACK-UP\((K03)\)
22
07000-B5125
O-RING\((K03)\)
23
01010-81875
BOLT
24
707-41-11840
WASHER
25
707-75-95030
RING, SNAP
26
707-36-13771
PISTON
27
707-44-13250
RING, PISTON\((K03)\)
28
707-39-13530
RING, WEAR\((K03)\)
29
707-44-13920
RING
30
01310-01216
SCREW
31
07000-B5085
O-RING\((K03)\)
32
707-35-30850
RING, BACK-UP\((K03)\)
-
724-Z0-17560
VALVE GROUP
33
707-83-13010
VALVE
34
07750-01628
SPRING
35
707-87-14071
PLUG
|$40
707-87-14070
PLUG
