Запчасти Komatsu PC200-8 МЕХАНИЗМ ПОВОРОТА И МОТОР (№87-) МЕХАНИЗМ ПОВОРОТА И МОТОР, ПОДАЮЩ. ONLY

|$0

20Y-26-00232

Swing Machinery Assembly

1

20Y-26-31120

Case

2

20Y-26-22331

Bearing

3

20Y-26-22342

Bearing

4

206-26-69112

Shaft

5

20Y-26-22420

Seal

6

20Y-26-22191

Cover

7

01010-81045

Bolt

8

01643-31032

Washer

9

07000-15310

O-ring

10

22U-26-21580

Carrier

11

22U-26-21540

Gear

12

20G-26-11241

Bearing

13

20Y-27-21240

Washer, Thrust

14

20Y-26-22250

Pin

15

20Y-27-21280

Pin

16

20Y-26-21240

Plate

17

112-32-11211

Bolt

18

22U-26-21551

Gear

19

20K-22-11190

O-ring

20

01010-81440

Bolt

21

01643-31445

Washer, Flat

22

22U-26-21530

Gear

23

22U-26-21572

Carrier

24

22U-26-21520

Gear

25

20Y-26-21281

Bearing

26

22U-26-21230

Washer, Thrust

27

22U-26-21210

Pin

28

04064-03515

Ring, Snap

29

22U-26-21250

Washer, Thrust

30

22U-26-21510

Gear

31

20Y-26-31510

Cover

32

01010-81035

Bolt

33

01643-51032

Washer

34

07042-30617

Plug, Taper

35

07042-30108

Plug

36

07040-12412

Plug

37

07002-12434

O-ring
