Запчасти Komatsu PC200-8 МОТОР ПОВОРОТА (/)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

706-7G-01170

MOTOR ASS'Y

|$3

706-7G-03130

MOTOR SUB ASS'Y

1

706-7G-41630

SHAFT,DRIVE

2

706-75-42880

BEARING

3

706-7G-41660

SPACER

4

706-76-40890

BEARING

5

706-7G-41510

SPACER KIT

5

SPACER,T=3.1MM

5

SPACER,T=3.4MM

5

SPACER,T=3.7MM

6

04064-04518

RING,SNAP

7

706-7E-11280

SEAL,OIL

8

706-7G-41910

SPACER

9

04065-06220

RING,SNAP

10

706-7G-41310

BLOCK,CYLINDER

11

706-7G-41720

PLATE,VALVE

12

706-75-43750

PIN,DOWEL

13

706-7G-41320

SHAFT,CENTER

14

706-7G-41130

RING,CENTER

15

706-7G-41140

SPRING

|$22

706-7G-05010

RETAINER KIT

16

RETAINER

17

SCREW

18

706-7G-41410

PISTON SUB ASS'Y

19

706-7G-91441

PLATE

20

706-7G-91450

DISC

21

706-7G-91120

PISTON,BRAKE

22

706-75-92310

O-RING

23

708-8F-31610

O-RING

24

706-7G-91360

SPRING
