Запчасти Komatsu PC200-8 ЦИЛИНДР СТРЕЛЫ(ЛЕВ.) (СИСТЕМА СМАЗКИ 100 ЧАС.) (WEBASTO ОБОГРЕВАТЕЛЬ. СПЕЦ-Я.)(№8-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XP600

CYLINDER GROUP,L.H. (FINAL COATING)

|$3

707-01-0K680

CYLINDER ASS'Y

1

707-13-12630

CYLINDER

2

707-58-85470

ROD,PISTON

3

205-70-71360

BUSHING

4

07145-00070

SEAL,DUST (KIT)

5

707-76-80010

BUSHING

6

07145-10080

SEAL,DUST (KIT)

7

707-71-34660

COLLAR

8

707-35-91220

RING,BACK-UP (KIT)

9

07000-55110

O-RING (KIT)

10

707-71-70800

PLUNGER

11

707-27-12650

HEAD,CYLINDER

12

707-56-85510

SEAL,DUST (KIT)

13

707-51-85730

PACKING,ROD (KIT)

14

707-51-85650

RING,BUFFER (KIT)

15

707-52-90611

BUSHING

16

707-35-91220

RING,BACK-UP (KIT)

17

07000-55110

O-RING (KIT)

18

01010-81695

BOLT

19

707-75-85110

RING,SNAP

20

01011-81600

BOLT

21

01643-51645

WASHER

22

707-88-05900

PLATE

23

707-88-04910

RING

24

707-56-85650

SEAL,DUST (KIT)

25

707-88-05890

COLLAR

26

700-11-31980

PLATE, NAME

27

707-36-12851

PISTON

28

707-44-12180

RING,PISTON (KIT)

29

707-39-12140

RING,WEAR (KIT)

30

707-44-12911

RING

31

07000-55075

O-RING (KIT)

32

707-35-90930

RING,BACK-UP (KIT)

33

01310-01216

SCREW

34

707-86-68180

TUBE,L.H.

35

20Y-62-24580

TUBE,L.H.

36

707-88-28010

BRACKET,L.H.

37

07372-21060

BOLT

38

01643-51032

WASHER

39

07372-21045

BOLT

40

01643-51032

WASHER

41

707-88-21620

BAND

42

07000-53030

O-RING (KIT)

43

07372-21035

BOLT

44

01643-51032

WASHER

45

07283-32738

CLIP

46

01597-01009

NUT

47

01643-31032

WASHER

|$52

707-99-46410

SERVICE KIT
