Запчасти Komatsu PC200-8 ЦИЛИНДР КОВША (СИСТЕМА СМАЗКИ 100 ЧАС.) (ДЛЯ ИНДОНЕЗ.) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XYG61

CYLINDER,(FINAL COATING)

G-1

707-01-XYG60

CYLINDER GROUP

|$5

707-01-0CG91

CYLINDER ASS'Y

|$6

707-01-0CG90

CYLINDER ASS'Y

1

707-13-11741

CYLINDER

1

707-13-11740

CYLINDER

2

707-76-70110

BUSHING

3

07145-00070

SEAL,DUST (KIT)

4

707-58-80871

ROD,PISTON

4

707-58-80870

ROD,PISTON

5

707-76-70120

BUSHING

6

20Y-70-23220

SEAL,DUST (KIT)

7

707-27-11870

HEAD,CYLINDER

8

707-88-39420

RING

9

707-56-80740

SEAL,DUST (KIT)

10

707-52-90561

BUSHING

11

707-75-80040

RING,SNAP

12

707-51-80030

PACKING,ROD (KIT)

13

07000-15105

O-RING (KIT)

14

707-35-91150

RING,BACK-UP (KIT)

15

707-51-80650

RING,BUFFER (KIT)

16

01010-81695

BOLT

17

01643-51645

WASHER

18

707-36-11880

PISTON

19

707-44-11250

RING,PISTON (KIT)

20

707-39-11530

RING,WEAR (KIT)

21

707-44-11920

RING

22

707-35-90360

RING (KIT)

23

07000-15070

O-RING (KIT)

24

01310-01216

SCREW

25

07020-00000

FITTING,GREASE

26

07020-00000

FITTING,GREASE

27

707-86-67750

TUBE

28

07372-21060

BOLT

29

01643-51032

WASHER

30

07372-21045

BOLT

31

01643-51032

WASHER

32

07000-13030

O-RING (KIT)

33

707-88-22570

BRACKET

34

707-88-21271

BAND

35

07372-21035

BOLT

36

01643-51032

WASHER

37

07283-32738

CLIP

38

01597-01009

NUT

39

01643-31032

WASHER

40

707-88-33030

CAP

41

07371-30640

FLANGE,SPLIT

42

07372-21035

BOLT

43

01643-51032

WASHER

44

707-88-04980

PLATE

45

707-56-80820

SEAL,DUST (KIT)

46

707-88-04970

COLLAR

47

010-11-81600

BOLT

KIT

707-99-45070

SERVICE KIT
