Запчасти Komatsu PC200-8 БЛОК КОНДИЦИОНЕРА ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

20Y-810-1211

AIR CONDITIONER

1

ND245450-5831

CASE,COOLING

2

ND245450-5840

CASE,COOLING

3

ND116576-3810

PLATE

4

ND116576-3820

PLATE

|5

ND446010-3132

EVAPORATOR,PART

5

ND446600-0991

EVAPORATOR ASS'Y

6

ND949142-0020

O-RING

7

ND949142-0030

O-RING

8

ND447500-2750

VALVE,EXPANSION

9

ND949046-3100

BOLT

10

ND146657-8841

PACKING

11

ND146657-9811

PACKING

12

ND146657-8850

PACKING

13

ND445021-3941

PLUG

14

ND116140-0050

CORE SUB ASS'Y,HEATER

15

ND116660-7570

DOOR SUB ASS'Y

16

ND116650-6850

DOOR SUB ASS'Y

17

ND116780-2481

LEVER SUB ASS'Y,LINK

18

ND116780-2491

LEVER SUB ASS'Y,LINK

19

ND116780-2501

LEVER SUB ASS'Y,LINK

20

ND116780-2510

LEVER SUB ASS'Y,LINK

21

ND116781-3000

LEVER

22

ND116780-3130

LEVER SUB ASS'Y,LINK

23

ND116662-7670

SHAFT

24

ND116662-7681

SHAFT

25

ND116576-3852

PLATE

26

ND116576-3862

PLATE

27

ND063800-0300

SERVO MOTOR ASS'Y

28

ND017231-0700

CLAMP

29

ND077500-5890

THERMISTOR ASS'Y

30

ND246790-2060

CLAMP

31

ND116780-3920

LEVER SUB ASS'Y,LINK

32

ND146667-0440

PACKING

33

ND077800-0750

POWER TRANSISTOR

34

ND146340-0560

BOX ASS'Y

35

ND063600-4580

SERVO MOTOR ASS'Y

36

ND077500-5650

THERMISTOR ASS'Y

37

ND146657-8860

PACKING

38

ND116340-7350

MOTOR ASS'Y,FAN

39

ND949008-0460

SCREW,TAPPING

40

ND949008-0330

SCREW,TAPPING

41

ND949001-1730

SCREW,TAPPING

42

ND246470-4311

HARNESS SUB ASS'Y,WIRE

43

ND93950-05003

FUSE

44

ND116662-8320

SHAFT
