Запчасти Komatsu PC200-7 ОХЛАЖД-Е (РАДИАТОР)(С КОНДИЦИОНЕРОМ) СИСТЕМА ОХЛАЖДЕНИЯ

1

20Y-03-31111

RADIATOR CORE ASS'Y

2

20Y-03-22110

CAP

3

20Y-03-21981

PLUG

4

07000-11007

O-RING

5

203-03-41410

HOSE

6

20Y-03-11330

CLIP

7

01435-20816

BOLT

8

20Y-03-31242

SEAL

9

20Y-03-31252

SEAL

10

20Y-03-31260

SEAL

11

20Y-03-31490

BRACKET

12

20Y-03-31270

SEAL

13

20Y-03-31152

FRAME

14

20Y-03-31162

FRAME

15

20Y-03-31170

FRAME

16

01010-81025

BOLT

17

01643-31032

WASHER

18

22U-03-21191

NET

19

01434-10616

BOLT, WING

20

01643-30623

WASHER

21

20Y-03-31181

PLATE

22

01010-81025

BOLT

23

01643-31032

WASHER

24

20Y-03-31420

NET

25

01434-10616

BOLT, WING

26

01643-30623

WASHER

27

20Y-03-31121

OIL COOLER ASS'Y

28

01010-81030

BOLT

29

01643-31032

WASHER

30

20Y-03-31480

VALVE ASS'Y

31

07000-12020

O-RING

32

07002-13034

O-RING

33

07040-11812

PLUG

34

07002-11823

O-RING

35

22U-03-21740

SHEET

36

20Y-03-31290

SEAL

37

22U-03-21760

SHEET

38

07040-11409

PLUG

39

07002-11423

O-RING
