Запчасти Komatsu PC200-7 ЦИЛИНДР КОВША (PC-7A) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XY830

CYLINDER GROUP

|$3

707-01-0A320

CYLINDER ASS'Y

1

707-13-11560

CYLINDER

2

707-76-70110

BUSHING

3

07145-00070

SEAL, DUST (KIT)

4

707-58-80651

ROD, PISTON

5

707-76-70120

BUSHING

6

20Y-70-23220

SEAL, DUST (KIT)

7

707-27-11981

HEAD, CYLINDER

8

07179-13094

RING, SNAP

9

195-63-92190

SEAL, DUST (KIT)

10

707-52-90560

BUSHING

11

707-51-80030

PACKING, ROD (KIT)

12

07000-15105

O-RING (KIT)

13

707-35-91150

RING, BACK-UP (KIT)

14

707-51-80640

RING, BUFFER (KIT)

15

01010-81670

BOLT

16

01643-51645

WASHER

17

707-36-11851

PISTON

18

707-44-11280

RING, PISTON (KIT)

19

707-39-11530

RING, WEAR (KIT)

20

707-44-11920

RING

21

707-35-90360

RING (KIT)

22

07000-15070

O-RING (KIT)

23

01310-01216

SCREW

24

07020-00000

FITTING, GREESE

25

07020-00000

FITTING, GREESE

26

707-86-66280

TUBE

27

01435-01055

BOLT

28

01435-01040

BOLT

29

07000-13030

O-RING (KIT)

30

707-88-22570

BRACKET

31

707-88-21271

BAND

32

01435-01030

BOLT

33

07283-22738

CLIP

34

01599-01011

NUT

35

01643-31032

WASHER

|$40

707-99-45230

SERVICE KIT
