Запчасти Komatsu PC200-7 ОСНОВН. КОНСТРУКЦИЯ (КОНСОЛЬ)(МАСТЕР КЛЮЧ)(ПРАВ.) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

1

22U-43-23110

STAY

2

22U-06-22330

HARNESS

3

22U-43-23120

BRACKET

4

22U-43-23130

STAY

5

22U-06-22320

COVER

6

22U-43-23140

COVER

7

22U-06-22420

POTENTIOMETER ASS'Y

8

22U-06-22470

KNOB

9

08086-20000

SWITCH

10

22U-06-22480

PLATE

11

22U-06-22190

SWITCH, BUZZER

12

22U-06-22290

SWITCH, SWING

13

22U-06-22390

SWITCH, LIGHT

14

20Y-06-23770

CLIP

15

20Y-06-23920

CLAMP

16

08034-10414

BAND

17

01023-60410

SCREW

18

01023-60512

SCREW

19

01023-10508

SCREW

20

01023-10512

SCREW

21

01601-20513

WASHER

22

01023-60620

SCREW

23

01023-70514

SCREW

24

22U-43-23210

COVER

25

20Y-06-31320

SWITCH ASS'Y

26

22U-43-23220

TRIM

27

22U-43-23230

COVER

28

22U-43-23240

FRAME

29

22U-43-23250

SHEET

30

22U-43-23260

CLIP

31

22U-43-23270

GROMMET

32

01370-00512

SCREW

33

01023-60616

SCREW

34

569-06-61960

RELAY

35

01435-00612

BOLT

36

01023-60410

SCREW

37

22U-43-23711

COVER

38

01023-10614

SCREW

39

01643-30623

WASHER

40

01010-81030

BOLT

41

01643-31032

WASHER
