Запчасти Komatsu PC200-7-AP ЦИЛИНДР КОВША (ДЛЯ 1.8M РУКОЯТИ) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XX200

CYLINDER GROUP,(FINAL COATING)

|1

707-01-0C880

CYLINDER ASS'Y

1

707-13-12500

CYLINDER

2

707-76-70690

BUSHING

3

07145-00070

SEAL,DUST (KIT)

4

707-58-85250

ROD,PISTON

5

707-76-70690

BUSHING

6

20Y-70-23220

SEAL,DUST (KIT)

7

707-27-12960

HEAD,CYLINDER

8

07179-13099

RING,SNAP

9

707-56-85510

SEAL,DUST (KIT)

10

707-52-90610

BUSHING

11

707-51-85030

PACKING,ROD (KIT)

12

07000-15115

O-RING (KIT)

13

707-35-91250

RING,BACK-UP (KIT)

14

707-51-85640

RING,BUFFER (KIT)

15

01010-81670

BOLT

16

01643-51645

WASHER

17

707-36-12030

PISTON

18

707-44-12280

RING,PISTON (KIT)

19

707-39-12560

RING,WEAR (KIT)

20

707-44-12921

RING

21

707-35-90930

RING,BACK-UP (KIT)

22

07000-15075

O-RING (KIT)

23

01310-01216

SCREW

24

07020-00000

FITTING,GREASE

25

07020-00900

FITTING,GREASE

26

707-86-66350

TUBE

27

01435-01055

BOLT

28

01435-01040

BOLT

29

07000-13030

O-RING (KIT)

30

707-88-22780

BRACKET

31

707-88-21530

BAND

32

01435-01030

BOLT

33

07283-22738

CLIP

34

01599-01011

NUT

35

01643-31032

WASHER

36

707-88-33030

HEAD

37

07371-30640

FLANGE,SPLIT

38

07372-21035

BOLT

39

01643-51032

WASHER

|K

707-99-46120

SERVICE KIT
