Запчасти Komatsu PC200-7-AP КОНЕЧНАЯ ПЕРЕДАЧА (ПОСТАВЛЯЕТСЯ ОТДЕЛЬНО)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

20Y-27-00301

FINAL DRIVE ASS'Y

|1

20Y-27-00300

FINAL DRIVE ASS'Y

1

708-8F-00171

MOTOR ASS'Y

|1

708-8F-00170

MOTOR ASS'Y

|2

150-27-00330

FLOATING SEAL ASS'Y

2

RING

3

O-RING

4

20Y-27-31220

HUB

5

20Y-27-22230

BEARING

6

20Y-27-22280

O-RING

7

20Y-27-22261

LOCK

8

20Y-27-22270

LOCK

9

01010-81020

BOLT

10

20Y-27-22170

CARRIER

11

20Y-27-22140

GEAR

12

20Y-27-22220

BEARING

13

20Y-27-21250

WASHER

14

20Y-27-21230

PIN

15

20Y-27-21290

PIN

16

20Y-27-13310

WASHER

17

20Y-27-22130

GEAR

18

20Y-27-22240

WASHER

19

20Y-27-22150

GEAR

20

20Y-27-22160

CARRIER

21

20Y-27-22120

GEAR

22

20Y-27-22210

BEARING

23

20Y-27-21240

WASHER

24

20Y-27-21220

PIN

25

20Y-27-21280

PIN

26

20Y-27-31210

SHAFT

27

20Y-27-21310

WASHER

28

20Y-27-31230

COVER

29

20Y-27-22250

BUTTON

30

20Y-27-13281

BOLT

31

01643-31645

WASHER

32

07049-01012

PLUG

33

07044-12412

PLUG

34

07002-12434

O-RING

35

20Y-27-11582

SPROCKET

36

20Y-27-11561

BOLT
