Запчасти Komatsu PC200-7-AP РУКОЯТЬ CRANE (РУКОЯТЬ СТОПОРН. КЛАПАН)(№-) СПЕЦ. ОПЦИИ

1

22U-62-27210

BRACKET

2

01010-81260

BOLT

3

20Y-62-13450

PLATE

|4

20Y-62-43172

BRACKET

4

CLAMP

5

20Y-62-45280

PLATE

6

20Y-62-13761

SEAT

|7

20Y-62-42962

BRACKET

7

CLAMP

8

20Y-62-45280

PLATE

9

205-62-73431

SEAT

10

20Y-62-13761

SEAT

11

20Y-62-42951

BRACKET

12

01010-81285

BOLT

13

20Y-62-13450

PLATE

|14

20Y-62-43172

BRACKET

14

CLAMP

15

20Y-62-45280

PLATE

16

20Y-62-13761

SEAT

|17

20Y-62-42962

BRACKET

17

CLAMP

18

20Y-62-45280

PLATE

19

205-62-73431

SEAT

20

20Y-62-13761

SEAT

21

20Y-62-42941

BRACKET

22

01010-81285

BOLT

23

20Y-62-13450

PLATE

24

20Y-62-42681

BRACKET

25

01010-81285

BOLT

26

20Y-62-13450

PLATE

27

20Y-62-42691

BRACKET

28

01010-81280

BOLT

29

20Y-62-13450

PLATE

30

20Y-62-42611

TUBE

31

02896-11018

O-RING

32

20Y-62-42621

TUBE

33

02896-11009

O-RING

34

20Y-62-13650

CLAMP

35

01010-81230

BOLT

36

01010-81235

BOLT

37

20Y-62-13450

PLATE

38

20Y-62-42811

CLAMP

39

21K-62-35270

CUSHION

40

01010-81230

BOLT

41

20Y-62-13450

PLATE

42

20Y-966-2310

CLAMP

43

01010-81230

BOLT

44

01010-81235

BOLT

45

20Y-62-13450

PLATE

46

07094-10315

CLAMP

47

07095-00314

CUSHION

48

01010-81265

BOLT

49

01643-31232

WASHER

50

07049-01215

PLUG
