Запчасти Komatsu PC200-6Z ТАБЛИЧКИ (ЯПОН.) (СЦЕПНОЕ УСТРОЙСТВО СДВИГ. ВВЕРХ СПЕЦ-Я.)(№9999-) МАРКИРОВКА

1

09685-00001

PLATE¤ OPERATING,SAFETY LOCK LEVER

2

205-00-73360

PLATE¤ OPERATING,HYDRAULIC OIL LEVEL

3

09690-M0063

PLATE¤ MARK

4

09690-B0315

PLATE¤ MARK

5

20Y-00-22780

PLATE¤ MARK,ONE POINT DECAL

6

20Y-00-21111

PLATE¤ MARK,PC200

7

14X-98-11141

PLATE¤ SAFETY,RADIATOR CAP

8

09652-01121

PLATE¤ CAUTION,FUEL INLET

9

203-00-61160

PLATE¤ SAFETY,HYDRAULIC OIL INLET

10

20Y-00-21121

PLATE¤ MARK,KEEP OFF SWING AREA

11

203-00-61410

PLATE¤ FUSE BOX

12

203-00-61210

PLATE¤ CAUTION,HAZARDOUS VOLTAGE HAZARD

13

14X-98-11280

PLATE¤ SAFETY,OPERATION AND MAINTENANCE

14

203-00-61180

PLATE¤ CAUTION,WINDOW LOCK

15

203-00-61170

PLATE¤ CAUTION,SAFETY LOCK LEVER

16

203-916-5730

PLATE¤ OPERATING,ISO PATTERN

17

20Y-00-21360

PLATE,HOOD

18

20Y-00-21151

PLATE,LUBRICATION CHART

19

203-00-61191

PLATE¤ CAUTION,BEFORE OPERATION

20

14X-98-11161

PLATE¤ SAFETY,TRACK ADJUSTMENT

21

14X-98-11380

PLATE¤ CAUTION,ACCUMULATOR

22

20Y-00-21161

PLATE¤ AVANCE DECAL

23

09601-00835

PLATE¤ NAME,MACHINE MODEL

24

04418-13060

SCREW

25

09963-00100

TAG,DO NOT OPERATE

26

203-00-52190

PLATE¤ CAUTION,WIPER MOTOR CONNECTOR

27

20Y-00-22811

PLATE,SPECIFICATION

28

203-00-51170

SEAT

29

154-54-23260

SEAT

30

20Y-00-22890

SHEET

31

20Y-54-36280

PLATE

32

20Y-00-22980

PLATE¤ MARK
