Запчасти Komatsu PC200-6Z РУКОЯТЬ (.8M) (ДЛЯ COMPONENT) РАБОЧЕЕ ОБОРУДОВАНИЕ

|$6

20Y-944-0021

ARM ASS'Y

|$7

20Y-944-0020

ARM ASS'Y

1

ARM

2

205-70-72180

BUSHING

2

205-70-66550

BUSHING

3

21K-70-12170

BUSHING

4

205-70-72130

BUSHING

5

07020-00900

FITTING

6

07020-00000

FITTING

7

07145-00090

SEAL

8

20Y-70-23220

SEAL

8

21K-70-12180

SEAL

9

205-70-62150

SEAL

10

20Y-70-11180

PIN

11

205-70-66580

PLATE

12

01010-81230

BOLT

12

01010-51230

BOLT

13

01643-31232

WASHER

14

205-70-71190

PIN

15

205-70-66580

PLATE

16

01010-81230

BOLT

16

01010-51230

BOLT

17

01643-31232

WASHER

18

205-63-X9100

CYLINDER GROUP,(SEE FIG.Y1620-41A1C)

18

205-63-X3140

BUCKET CYLINDER G.,(SEE FIG.Y1620-41A1)

18

205-63-X3140

BUCKET CYLINDER G.,(FOR JAPAN)

18

205-63-X2140

BUCKET CYLINDER G.,(EXCEPT JAPAN)

18

205-63-X2140

BUCKET CYLINDER G.,(SEE FIG.Y1620-41A1)

19

07378-10600

HEAD

20

07000-13025

O-RING

21

07371-30640

FLANGE

22

07372-21035

BOLT

23

01643-51032

WASHER
