Запчасти Komatsu PC200-6Z ОСНОВН. КЛАПАН (-АКТУАТОР) (/)(№89-9998) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$3

723-48-11501

VALVE ASS'Y

|$4

723-48-11500

VALVE ASS'Y

|$5

723-48-11105

VALVE ASS'Y

|$7

723-40-66300

VALVE ASS'Y

1

CASE

2

SEAT

3

SEAT

4

BALL

5

PLUG

|$13

723-46-40500

VALVE ASS'Y

6

SLEEVE

7

VALVE

8

SPRING

9

SEAL

10

700-93-11320

O-RING

11

723-46-41950

RING

12

07002-13634

O-RING

|$21

709-70-74600

VALVE ASS'Y,SUCTION AND SAFETY

13

SLEEVE

14

SLEEVE

15

POPPET

16

PISTON

17

PLUG

18

POPPET

19

SCREW

20

SPRING

21

SPRING

22

SPRING

23

SEAL

24

SEAL

25

709-25-11390

O-RING

26

O-RING

27

O-RING

28

NUT

|$38

723-46-48100

VALVE ASS'Y

29

SLEEVE

30

VALVE

31

SEAT

32

POPPET

33

PLUG

34

SCREW

35

NUT

36

NUT

37

SPRING

38

SPRING

39

PLATE

40

CAP

41

SEAL

42

SEAL

43

700-93-11320

O-RING

44

723-46-41950

RING

45

07002-13634

O-RING

46

O-RING

47

RING

48

O-RING

49

RING,BACK-UP
