Запчасти Komatsu PC200-6Z ОСНОВН. КЛАПАН (/)(№9-997) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

723-46-13302

VALVE ASS'Y

|$4

BODY SUB ASS'Y

1

BLOCK,VALVE

2

SPOOL

3

SPOOL

4

SPOOL

5

SPOOL

6

SPOOL

7

723-46-15130

PLUG

8

723-46-15140

PLUG

9

07002-10823

O-RING

10

723-46-16171

PLUG

11

07002-11023

O-RING

12

07000-11005

O-RING

13

07001-01005

RING,BACK-UP

14

708-7T-16460

BALL

15

723-46-15120

RETAINER

16

723-46-16160

RETAINER

17

723-46-14110

SPRING

18

723-46-14170

SPRING

19

723-46-14131

SPRING

20

723-46-15110

CASE

|$25

723-46-00710

CASE SUB ASS'Y

21

CASE

22

PISTON

23

PISTON

24

SEAL

25

PLUG

|$31

723-46-00720

CASE SUB ASS'Y

26

CASE

27

PISTON

28

PISTON

29

PISTON

30

SEAL

31

PLUG

32

07430-71380

O-RING

33

01252-60820

BOLT

34

01252-60860

BOLT

35

723-46-16190

NUT

36

PLUG

37

723-46-15150

VALVE

38

723-46-14150

SPRING

39

708-8H-11530

PLUG

40

07002-11423

O-RING
