Запчасти Komatsu PC200-6S НАГНЕТАТЕЛЬ В СБОРЕ (С КОНДИЦИОНЕРОМ)(№8-98) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

ND116300-3513

BLOWER ASS'Y,(FOR SUPPLY)

|1

ND116300-1871

BLOWER ASS'Y

1

ND116250-3764

CASE,(FOR SUPPLY)

|1

ND116250-3760

CASE

2

ND116530-9081

DAMPER,(FOR SUPPLY)

|2

ND116530-9080

DAMPER

3

ND949013-3690

WASHER

4

ND016657-0311

INSERT

5

ND116290-0720

FLANGE,(FOR SUPPLY)

|5

ND116290-0650

FLANGE

6

ND949001-2690

SCREW,(FOR SUPPLY)

|6

ND91570-06141

BOLT

7

ND017732-3721

LEVER

8

ND91370-03081

SCREW

9

20Y-979-2940

MOTOR

10

ND116662-1880

SHAFT

11

ND146691-2790

CLAMP

12

ND90930-05161

SCREW

13

17M-911-3290

CLAMP

14

ND146622-6880

PACKING

15

ND116340-2960

MOTOR,(FOR SUPPLY)

|15

ND116340-2550

MOTOR

|15

ND116221-0960

FAN

|15

ND017231-2370

CLAMP

16

ND146525-3010

BRACKET,(FOR SUPPLY)

|16

ND246611-9990

BRACKET

17

ND949047-2370

BOLT,(FOR SUPPLY)

|17

ND91478-05158

BOLT

18

ND90930-06201

SCREW

19

ND146651-1840

PIPE

20

ND146810-9281

RESISTOR,(FOR SUPPLY)

|20

ND146810-9280

RESISTOR

21

ND90930-04161

SCREW

22

ND058700-2801

RELAY

23

ND116621-8270

PLATE,(FOR SUPPLY)
