Запчасти Komatsu PC200-6S ОСНОВН. КЛАПАН (-АКТУАТОР) (/) (ДЛЯ РУКОЯТИ ВРАЩЕНИЕ)(№88-9998) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

723-49-12402

VALVE ASS'Y

|1

723-49-12401

VALVE ASS'Y

|1

723-49-12400

VALVE ASS'Y

|1

723-40-66300

VALVE ASS'Y

1

CASE

2

SEAT

3

SEAT

4

BALL

5

PLUG

|6

723-46-48100

VALVE ASS'Y

6

SLEEVE

7

VALVE

8

SEAT

9

POPPET

10

PLUG

11

SCREW

12

NUT

13

NUT

14

SPRING

15

SPRING

16

PLATE

17

CAP

18

SEAL

19

SEAL

20

700-93-11320

O-RING

21

723-46-41950

RING

22

07002-13634

O-RING

23

O-RING

24

RING

25

O-RING

26

RING,BACK-UP

|27

723-46-40100

VALVE ASS'Y

27

SLEEVE

28

PISTON SUB ASS'Y

29

SPRING

30

SEAL

31

700-93-11320

O-RING

32

723-46-41950

RING

33

07002-13634

O-RING

|34

709-70-74600

VALVE ASS'Y,SUCTION AND SAFETY

|34

709-70-74402

VALVE ASS'Y,SUCTION AND SAFETY

34

SLEEVE

35

SLEEVE

36

POPPET

37

PISTON

38

PLUG

39

POPPET

40

SCREW

41

SPRING

42

SPRING

43

SPRING

44

SEAL

45

SEAL

46

709-25-11390

O-RING

47

O-RING

48

O-RING

49

NUT

|50

723-40-85100

VALVE ASS'Y,SUCTION

50

SLEEVE

51

VALVE

52

SPRING

53

SEAL

54

709-25-11390

O-RING
