Запчасти Komatsu PC200-6S КЛАПАН PPC(ДЛЯ ХОДА)(№C-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

702-16-01540

PILOT VALVE

1

BODY,VALVE

2

VALVE

3

702-16-51140

SHIM¤ 0.30MM,0.3MM

4

702-16-53420

SPRING

5

702-16-53140

RETAINER

6

702-16-54420

SPRING

7

702-16-53170

PISTON

8

702-16-51270

SEAL

9

07000-02020

O-RING

10

702-16-54170

COLLAR

11

702-16-54310

CASE

12

LEVER

13

SHAFT

14

PLATE

15

01010-80855

BOLT

16

01643-30823

WASHER

17

01010-80816

BOLT

18

702-16-54331

WASHER¤ 1.60MM,1.6MM

19

04025-00432

PIN,SPRING

20

702-16-54430

BUSHING

21

702-16-54341

WASHER¤ 1.30MM,1.3MM

22

702-16-54351

WASHER¤ 1.00MM,1.0MM

23

702-16-54280

SEAL,DUST

24

702-16-54500

DAMPER ASS'Y

25

01252-30525

BOLT

26

702-16-54510

PLATE

27

04025-00420

PIN,SPRING

28

LEVER

29

01224-40612

SCREW

30

PLUG

31

PLUG

32

07040-11209

PLUG

33

07002-11223

O-RING

34

700-84-11730

BALL

35

702-16-55940

PLUG

36

702-16-55950

SEAT
