Запчасти Komatsu PC200-6S ОСНОВН. КЛАПАН (-АКТУАТОР) (/)(№C-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

723-47-13406

CONTROL VALVE

|1

723-47-13405

CONTROL VALVE

|1

BODY SUB ASS'Y

|1

723-46-48100

VALVE ASS'Y

1

SLEEVE

2

VALVE

3

SEAT

4

POPPET

5

PLUG

6

SCREW

7

NUT

8

NUT

9

SPRING

10

SPRING

11

PLATE

12

CAP

13

SEAL

14

SEAL

15

700-93-11320

O-RING

16

723-46-41950

RING

17

07002-13634

O-RING

18

O-RING

19

RING

20

O-RING

21

RING,BACK-UP

22

01252-60845

BOLT

23

01643-50823

WASHER

|24

723-40-66300

VALVE ASS'Y

24

CASE

25

SEAT

26

SEAT

27

BALL

28

PLUG

|29

709-70-74600

VALVE ASS'Y,SUCTION AND SAFETY

29

SLEEVE

30

SLEEVE

31

POPPET

32

PISTON

33

PLUG

34

POPPET

35

SCREW

36

SPRING

37

SPRING

38

SPRING

39

709-70-71610

SEAL

40

SEAL

41

O-RING

42

O-RING

43

O-RING

44

NUT
