Запчасти Komatsu PC200-6LC ШАТУН И ПОРШЕНЬ ДВИГАТЕЛЬ

Схема запчастей Komatsu PC200-6LC - ШАТУН И ПОРШЕНЬ ДВИГАТЕЛЬ
7
5
3
6
8
1
6
4
2

Артикул

Название

Примечание

Количество

|$0

6732-31-3100

KIT, ENGINE CONNECTING ROD

1

NSS

ROD, ENGINE CONNECTING

2

6732-31-3310

BOLT, CONNECTING ROD CAP

3

6732-31-3130

BUSHING CONNECTING ROD

4

6732-31-3410

BEARING, CONNECTING ROD HALF

|$5

6736-39-3400

BEARING, CONNECTING ROD HALF - 0.25MM OVERSIZE

|$6

6736-38-3400

BEARING, CONNECTING ROD HALF - 0.50MM OVERSIZE

|$7

6736-37-3400

BEARING, CONNECTING ROD HALF - 0.75MM OVERSIZE

|$8

6736-36-3400

BEARING, CONNECTING ROD HALF - 1.00MM OVERSIZE

5

6735-01-3110

KIT, ENGINE PISTON STD

|$10

NSS

PISTON, ENGINE

6

6736-31-2510

RING, RETAINING

7

6736-31-2030

SET, PISTON RING

8

6736-31-2420

PIN, PISTON

5

1294 355 H91

KIT, ENGINE PISTON .5MM OVERSIZE

|$15

NSS

PISTON, ENGINE

6

6736-31-2510

RING, RETAINING

7

6736-31-2040

SET, PISTON RING

5

6735-38-2010

KIT, ENGINE PISTON 1.0MM OVERSIZE

|$19

NSS

PISTON, ENGINE

6

6736-31-2510

RING, RETAINING

7

6736-31-2050

SET, PISTON RING

Выбрано товаров: 22
