Запчасти Komatsu PC200-6L FIG NO. H- ГИДР. БАК. (С ДАТЧИКОМ) ГИДРАВЛИКА

|$0

20Y-60-00061

TANK ASSEMBLY, HYDRAULIC

1

20Y-60-21113

TANK, HYDRAULIC

2

208-04-19130

ELBOW

3

203-60-31160

TUBE

4

07044-12412

PLUG

5

07002-02434

O-RING

6

20Y-966-2970

TEE

7

07002-02434

O-RING

8

07236-10628

ELBOW

9

07002-02434

O-RING

10

20Y-60-21211

CASE

11

07063-01210

ELEMENT, HYDRAULIC TANK

12

206-60-41221

STRAINER, HYDRAULIC TANK

13

12R-60-11300

VALVE ASSEMBLY

14

20Y-60-21240

SPRING

15

20Y-60-21250

COVER

16

07000-05165

O-RING

17

01010-51240

BOLT

18

01643-31232

WASHER

19

20Y-60-21220

HEAD

20

07000-05210

O-RING

21

20Y-60-21230

RING

22

20Y-60-21260

PACKING

23

01010-51240

BOLT

24

01643-31232

WASHER

25

7861-92-4210

SENSOR

26

01252-40612

BOLT

27

01641-20608

WASHER

|$28

20Y-60-21301

STRAINER ASSEMBLY

28

20Y-60-21330

ROD ASSEMBLY

29

20Y-60-21320

HOLDER

30

12R-60-11230

SPRING

31

01580-11008

NUT

32

20Y-60-21311

STRAINER, HYDRAULIC TANK

33

NSS

COVER

34

07000-05180

O-RING

35

01010-51225

BOLT

36

01643-31232

WASHER

37

20Y-60-21440

CAP

38

20Y-60-21460

NECK

39

205-60-51460

GASKET

40

01220-40516

SCREW

41

01601-20513

WASHER

42

07285-00155

CLIP

43

07270-61509

TUBE

44

01010-51635

BOLT

45

01643-31645

WASHER

46

209-62-57210

TEE

47

07002-02034

O-RING
