Запчасти Komatsu PC200-6L FIG NO. A-AG БЛОК ЦИЛИНДРОВ ДВИГАТЕЛЬ

|$0

6209-21-1200

CYLINDER BLOCK ASSEMBLY

1

NSS

BLOCK, CYLINDER

2

6206-21-1430

BUSHING, CAMSHAFT

3

6206-21-1420

BUSHING, CAMSHAFT

4

6204-29-1210

CAP, MAIN BEARING - NO. 1, 2, 3, 4, 5, 6

5

6204-29-1220

CAP, MAIN BEARING - NO. 7

6

6141-21-1530

RING, DOWEL

7

04025-00408

PIN, SPRING

8

6204-21-1610

BOLT, MAIN CAP

9

6204-51-1711

BUSHING, OIL PUMP

10

6209-51-1620

SHAFT, OIL PUMP

11

07046-41810

PLUG

12

04020-00820

PIN, DOWEL

13

6136-52-1620

PIN, DOWEL - OIL PUMP

14

07046-42216

PLUG

15

04020-01228

PIN, DOWEL

16

07046-43016

PLUG

17

07046-42516

PLUG

18

07042-00312

PLUG

19

07043-00108

PLUG

20

07043-50211

PLUG

21

6140-21-1130

BUSHING, DOWEL

22

6207-21-1180

PIN

23

07046-44016

PLUG

24

07046-23016

PLUG

25

6207-21-2110

LINER, CYLINDER

|$26

6207-21-2120

LINER, CYLINDER

26

08073-10505

SWITCH, OIL PRESSURE

27

08073-10515

SWITCH, OIL PRESSURE
