Запчасти Komatsu PC200-6L FIG NO. H-7 ОСНОВН. КЛАПАН ( АКТУАТОР) (7/9) РАЗГРУЗ. КЛАПАН ГИДРАВЛИКА

|$2

723-40-50100

VALVE ASSEMBLY, RELIEF

1

NSS

SLEEVE

2

NSS

PLUG

3

NSS

PLUG

4

NSS

VALVE

5

NSS

PISTON

6

NSS

RETAINER

7

NSS

SPRING

8

NSS

POPPET

9

NSS

PISTON

10

NSS

SPRING

11

NSS

SLEEVE

12

NSS

RETAINER

13

NSS

NUT

14

NSS

SLEEVE

15

NSS

PISTON

16

700-80-61260

O-RING

17

700-80-61430

RING

18

07000-12021

O-RING

19

07001-02021

RING

20

07002-13034

O-RING

21

709-25-11390

O-RING

22

07000-12018

O-RING

23

07001-02018

RING

24

07000-03032

O-RING

25

NSS

O-RING

26

NSS

SEAL

|$29

723-40-50200

VALVE ASSEMBLY, RELIEF

27

709-20-51113

SLEEVE

28

709-20-51260

VALVE

29

700-80-61190

POPPET

30

709-20-51231

SPRING

31

709-20-51280

SCREW

32

709-20-51270

SPRING

33

700-20-51240

RING

34

01582-11411

NUT

35

700-22-11410

O-RING

36

700-80-64220

RING

37

07002-02434

O-RING

38

07000-02011

O-RING
