Запчасти Komatsu PC200-6J СОЛЕНОИДНЫЙ КЛАПАН(№987-9998) ГИДРАВЛИКА

|1

206-60-51100

VALVE ASS'Y

1

206-60-51130

SOLENOID VALVE

2

206-60-51140

BLOCK

3

07230-20210

UNION

4

208-62-17550

TEE

5

07002-01423

O-RING

6

07235-10315

ELBOW

7

07002-02034

O-RING

8

07235-10315

ELBOW

9

07002-02034

O-RING

10

20Y-62-22330

ELBOW

11

07002-02034

O-RING

12

01010-51095

BOLT

13

01643-31032

WASHER

14

20Y-60-11410

ACCUMULATOR

15

20Y-62-22310

ELBOW

16

07002-02034

O-RING

17

07283-23450

CLIP

18

01599-01011

NUT

19

01643-31032

WASHER

20

08034-00536

BAND

21

203-62-52310

HOSE¤ 700MM

22

20Y-62-22860

BAND¤ BROWN

23

203-62-52260

HOSE¤ 1300MM

24

20Y-62-22810

BAND¤ YELLOW

25

203-62-52290

HOSE¤ 1100MM

26

20Y-62-22951

HOSE

27

20Y-62-22790

BAND¤ RED

28

20Y-62-22990

HOSE¤ 2150MM

29

20Y-62-22820

BAND¤ BLUE

30

20Y-62-22981

HOSE¤ 600MM

31

20Y-62-21930

HOSE¤ 980MM

32

04434-52712

CLIP

33

01010-51230

BOLT

34

01643-31232

WASHER

35

04434-51512

CLIP

36

01010-51225

BOLT

37

01643-31232

WASHER

38

08034-00519

BAND
