Запчасти Komatsu PC200-6J НАВЕСНОЕ ОБОРУД-Е ( АКТУАТОР) (SIMPLE) (/)(№9-) ГИДРАВЛИКА

1

20Y-62-25110

BLOCK

2

21T-09-11450

O-RING

3

20Y-62-25120

PLATE

4

21T-09-11470

O-RING

5

01252-41025

BOLT

6

208-62-51340

HOSE

7

07371-31049

FLANGE

8

07372-21035

BOLT

9

01643-51032

WASHER

10

07000-13032

O-RING

11

20Y-970-6210

TUBE

12

20Y-970-6251

BRACKET

13

01010-81660

BOLT

14

01643-31645

WASHER

15

20Y-62-25173

BRACKET

16

01010-81275

BOLT

17

01643-31232

WASHER

18

20Y-62-13651

CLAMP

|18

20Y-62-13650

CLAMP

|18

20Y-62-13651

CLAMP

|18

20Y-62-13650

CLAMP

19

01010-81230

BOLT

20

20Y-62-13450

PLATE

21

07283-33450

CLIP

22

01599-01011

NUT

23

01643-31032

WASHER

24

07283-53444

SEAT

25

20Y-970-1981

BRACKET

26

07283-23442

CLIP

27

01599-01011

NUT

28

01643-31032

WASHER

29

20Y-62-25131

TUBE

30

01010-81040

BOLT

31

01643-51032

WASHER

32

21T-09-11460

O-RING

33

20Y-62-25241

BRACKET

34

01010-81095

BOLT

35

01643-31032

WASHER

36

07283-22738

CLIP

37

01599-01011

NUT

38

01643-31032

WASHER

39

20Y-62-25140

HOSE

40

07371-31049

FLANGE

41

07372-21035

BOLT

42

01643-51032

WASHER

43

07000-13032

O-RING

44

20Y-970-6220

TUBE

45

20Y-62-25173

BRACKET

46

01010-81275

BOLT

47

01643-31232

WASHER

48

20Y-970-6180

BRACKET

49

01010-81660

BOLT

50

01643-31645

WASHER

51

07283-32746

CLIP

52

01599-01011

NUT

53

01643-31032

WASHER

54

07283-52737

SEAT
