Запчасти Komatsu PC200-6J ГЛАВН. КЛАПАН(№9999-9) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

702-21-09143

VALVE ASS'Y

1

BLOCK

2

VALVE

3

702-21-55460

SPRING

4

702-21-55420

O-RING

5

702-21-55430

O-RING

6

702-21-55440

O-RING

7

702-21-53120

FILTER

8

07000-11009

O-RING

9

702-21-55410

PLATE

10

01252-60820

BOLT

11

01643-50823

WASHER

12

702-21-55450

O-RING

13

BLOCK

14

SPOOL

15

SLEEVE

16

SPRING

17

SCREW

18

SPRING

19

WASHER

20

POPPET

21

702-21-55620

PLUG

22

07002-11423

O-RING

23

NUT

24

O-RING

25

O-RING

26

07002-11623

O-RING

27

702-21-55710

SEAT

28

702-21-55720

SPRING

29

04260-00793

BALL

30

07000-11009

O-RING

31

PLUG

32

702-21-55670

ORIFICE

33

702-21-55470

ORIFICE

34

01252-60520

BOLT

35

702-21-55480

FRANGE

36

07000-12020

O-RING

37

01252-61025

BOLT
