Запчасти Komatsu PC200-6B ГЛАВН. КЛАПАН ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
1
24
5
7
4
13
17
16
25
31
20
19
18
21
2
3
12
9
11
10
31
27
26
28
22
6
8
23
14
15
37
39
30
31
36
29
32
33
34
38
35
|1
702-21-09147
VALVE ASS’Y
1
BLOCK
2
702-21-55310
VALVE
3
702-21-55460
SPRING
4
702-21-55420
O-RING
5
702-21-55520
O-RING
6
702-21-55440
O-RING
7
702-21-53120
FILTER
8
07000-11009
O-RING
9
702-21-55410
PLATE
10
01252-60820
BOLT
11
01643-50823
WASHER
12
702-21-55530
O-RING
13
BLOCK
14
SPOOL
15
702-21-55640
SPRING
16
702-21-55620
PLUG
17
07002-11423
O-RING
18
702-21-55710
SEAT
19
702-21-55720
SPRING
20
04260-00793
BALL
21
07000-11009
O-RING
22
PLUG
23
702-21-55670
ORIFICE
24
702-21-55470
ORIFICE
25
01252-60520
BOLT
26
702-21-55480
FRANGE
27
07000-12020
O-RING
28
01252-61025
BOLT
|29
702-21-55100
VALVE ASS’Y
29
SLEEVE
30
COLLAR
31
FILTER
32
POPPET
33
SPRING
34
SCREW
35
NUT
36
O-RING
37
702-16-53920
O-RING
38
O-RING
39
07002-11623
O-RING
